Ryair - Two-Stage Rotor Concentrator
After pretreatment of filtering and cooling, the organic waste gas with middle and high concentration enters the first-stage rotor and the second-stage rotor for adsorption and concentration. By now we will get clean gas which can be discharged by standard through the chimney. The high-concentration desorbed gas generated by the rotor enters the drying tank to completely remove the moisture after heating recovery. We will obtain a water-free solvent after the dried exhaust gas condensed at a deep low-temperature(-60 to -10 °C can be selected according to the VOCs composition). The condensed exhaust gas still contains a certain concentration of VOCs components, and finally it will return to the inlet manifold process of device.
- Suitable for large air volume + medium to high concentration of exhaust gas and other working conditions.
- The exhaust gas will be discharged by standard.
- High recovery benefits.
- Recovering solvent with water content 0.1% ~ 0.4%.
- Customized design according to working conditions, low energy consumption, 24h continuous and stable operation.
- Low maintenance cost and long life span.
Suitable for the exhaust gas treatment field with large air volume, medium to high concentration and recovery value. The main application industries are painting, tape, packaging, printing, electrician, insulation, new materials, coating, etc.
