ULC - Model PRX Dual -Live Gas Main Camera Inspection System
The PRX Dual Live Gas Main Camera Inspection System combines two of the most comprehensive, innovative live gas camera systems to provide natural gas utilities with the highest quality, most cost effective and reliable pipeline inspection possible.
Utilities are facing increasing paving and restoration costs. Reduce those costs and maximize travel distance by inspecting up to 800ft (240m) from just one excavation.
Gas utilities use the PRX Dual system to identify and locate features in the main such as joints, drip pots, valves and more.
Visually inspect and verify PE fusions, coupling installations and tee installations.
The PRX Dual system, launch method and operation procedures, were designed in partnership with the gas utility industry to ensure the highest levels of safety.
Identify undocumented service taps, stub service taps, crosses and tees and utilize data collected from the PRX Dual system to know your mains.
Customers use the PRX Dual system to aid in leak detection by looking for visual evidence such as cracks, leak paths or corrosion.
- Diameter Range:
- 2″ – 4″ / 63 – 101mm Plastic
- 4″ – 12″ / 101 – 315mm Plastic, Steel & Cast Iron
- Max Pressure: 60psi / 4bar
- Camera Type: Wide Angle, Fixed
- Tether Length: 400ft / 120m
