Ulrich - Side Dump Bucket

Designed for general earthmoving duties in restricted conditions. Rugged yet simple construction, incorporating materials carefully chosen for strength and durability allowing weight to be kept to the minimum.

Capacities start at 0.7m³ and when Side Dumping gives additional discharge height above that obtained with a conventionally mounted standard bucket.

The bucket is pin mounted on a carrying cradle and the side dump action is activated by a single hydraulic cylinder. A ‘Tiplock’ is fitted to automatically lock the bucket to the cradle for normal loader operations.

The side Dump bucket is fully interchangeable with standard and multipurpose buckets and uses the third spool of the loader control valve and pipework for operation.
