Ouster - Model OS0 -Ultra-Wide View Lidar Sensor

Ultra-wide vertical field of view

LIDAR THAT SEES MORE
Enhance situational awareness with the OS0’s 90º field of view and minimum detection range of zero.

Lightweight modular design

INTEGRATION OPTIONS FOR ANY DEPLOYMENT
Weighing only 447 g and featuring a modular cap design, this lidar sensor seamlessly integrates into your vehicle, drone, or robot.

Rugged and reliable

ALL-WEATHER TOUGH
Ouster lidar sensors are designed for 100,000 hours of continuous use. Water-proof, robust to shock and vibration, and temperature rated from -40 ºC to +60 ºC.

Data quality

ALGORITHM OPTIMIZED
The structured digital lidar data output and unmatched intensity data quality from Ouster lidar sensors improves algorithm efficiency and accuracy.

Upgradeable firmware

GREAT KEEPS GETTING BETTER
Frequent firmware updates add features and improve sensor performance, helping you get more out of your sensors.

• PTP and NMEA/PPS time synchronization options
• On-the-fly programming of frame rate and horizontal resolution
• Fixed angle data measurement
• Multi-sensor crosstalk resistance
• Pluggable space-style bayonet connector
• Over-the-network firmware updates
• Class 1 Eye Safe per IEC/EN 60825-1:2014
• Output: range, intensity, reflectivity, ambient NIR, azimuth angle, time stamp
