Aquatic - Model OSR-UPWS-25/50 -Ultrapure Laboratory-Grade Water Systems
Established in 2006, we have goal of providing high quality service worldwide. We are unique with combination of Knowledge & Experience in Water Treatment. We provide comprehensive spectrum of technologies for producing all grades of Water required in Testing Lab, R&D and Production. For laboratories that do not have a reliable source of pure water, Aquatic Solutions offers compact water systems producing pure and ultrapure water directly from tap water.
This concept offers several benefits:
It allows installation of a complete water system in minimum amount of space in any lab with tap water feed
It eliminates the need for central water purification systems and the associated water delivery loops which may be complex, expensive, difficult to
maintain and to extendlt gives the users of the water system complete control over all water purification steps and the final water quality.
INSIDE OSR-UPWS-25/50
Three Stage Pre-Treatment Systems
- 1st Stage: Removes Particles upto 0.5 microns, avoids clogging of system
- 2n Stage: Removes free Chlorine & colloids to protect the system
- 3r Stage: Removes Particles upto 0.5 microns ensures complete safety for system
Advance Reverse Osmosis
Reverse Osmosis (RO), the second step removes 90-95% of ions and 99% of all dissolved organic substances (MW>200 Daltons), micro-organisms and particles. Safety features like low pressure switch & auto flushing valve are provided to ensure efficient working & lower maintenance.
Polishing Deionizer
Ultrapure Water of very low conductivity is achieved through this unit which cannot be otherwise obtained by any commercial production methods.
The Internal Chemical Media which needs to be replaced after 4000 lit of deionized water is extracted from it. It may vary from case to case basis, our expert engineers are best to judge and suggest.
Ultraviolet Lamp (UV)
Water is Sanitize with a high dose of ultra violet light energy at a wave length of 254 nanometers destroys pathogenic microbes by affecting the DNA in the cell and multiplication of micro-organisms gets stopped with this they can`t reproduce. When we use UV with RO-DM Technology, UV Technology provides additional sterilization to the water leaving no scope for bacteria. It is the final stage of purification system.
