Chao Sensor - Model CC-M15-C -Ultrasonic Wind Speed and Direction Meter
The CC-M15-C combines both wind speed and direction measurement functionalities into a single, compact unit. Utilizing advanced ultrasonic technology, it ensures accurate and reliable real-time data acquisition. This sensor is ideal for various applications, including meteorological monitoring, marine navigation, and aviation. The device features robust construction suited for harsh environmental conditions, guaranteeing durability and minimal maintenance. Its integration into SCADA and telemetry systems enhances operational efficiency. With zero moving parts, wear and tear are virtually non-existent, ensuring long-term stability and precision.
Integrated wind speed and direction sensor is a wind speed and direction measuring instrument independently developed and produced by our company. The sensor shell is made of polycarbonate composite material, which has good anti-corrosion characteristics, which can ensure long-term use of the sensor without rust. At the same time, it cooperates with the internal smooth bearing system to ensure the stability of information collection. Internal integration of photoelectric conversion mechanism, industrial microcomputer processor, standard current generator, current driver, etc. The circuit is designed according to EMI specifications, making the whole with extremely reliable anti-electromagnetic interference ability, and the electronic components are imported industrial-grade chips to ensure the stability of the measurement parameters and electrical performance.
- It adopts an integrated design, which is small in size and easy to install.
- High measurement accuracy, fast response speed and good interchangeability.
- Realize low cost, low price and high performance.
- High data transmission efficiency and reliable performance to ensure normal work.
- The power supply has a wide range of adaptation, good data information linearity, and long signal transmission distance.
This product is widely used in construction machinery, railway, port, wharf, power plant, meteorology, ropeway, environment, greenhouse, breeding and other fields for measuring wind speed and wind direction.
- Wind Speed Measurement Range: 0-30m/s; 0-50m/s; 0-60m/s; (Other ranges can also be customized)
- Wind Direction Measurement Range: 8 Directions
- Starting Wind Speed: ≤0.3m/s
- Accuracy: ±(0.3+0.03V) m/s, ±1°
- Output Signal:
- A: Voltage signal (Choose one of 0-2V, 0-5V, 0-10V)
- B: 4-20mA (Current loop)
- C: RS485 (Standard Modbus-RTU protocol, device default address: 01)
- D: SDI-12 (American Hydrological Organization Serial Data
- Communication Interface Protocol)
- Sensor Supply Voltage (red and black lines):
- 5-24V DC (When the output signal is 0~2V, RS485, Pulse signal, SDI-12)
- 12-24V DC (When the output signal is 0-5V, 0-10V, 4-20mA)
- Heating Power Supply Voltage (brown and white line): 12-24V DC
- Heating Power: Average: 160mA@12V; 310mA@24V
- Stability Time: <1 second
- Response Time: <1 second
- Working Environment: Temperature: 0~50°C; Humidity: <95%RH
- Storage Environment: Temperature: 0~50°C; Humidity: <95%RH
