Tanco - Model PLT-125 A -Universal Digital Oven
Double Walled Oven Universal (Memmert Type) is elegantly designed in various applications for microbiology, cell cultivation of animals and plants, food studies; general heating, drying, sterilizing, baking, to perform: material tests, ageing of computer chips, run complex experiments with highly sensitive loads, drying or tempering electronic components, hardening plastic resin. Our U universal oven stands for unparalleled precise, even and gentle temperature control. Double Walled Oven Universal (Memmert Type) is low cost options for heating- for various experiments in, industries, R&D labs, Pharmaceutical, Food & Beverage Industries and Institutions- in the field of Medical, Agricultural and Industrial Research.
- Outer chamber is made of Mild Steel duly powder coated.
- Inner chamber made of ALUMINIUM or STAINLESS STEEL (304) sheet.
- Forced convection system by motor & blowers fitted ensures good mixing, strong dispersion and maintains higher temperature uniformity inside the chamber & no cross contamination.
- Thermal loss is prevented by filling mineral wool (Insulation) in space between the outer body & Inner chamber.
- Door Gasket fixed on the double walled door for proper sealing.
- Fitted with heavy hinges with a ball catcher, spring loaded door closing device. Door is duly insulated.
- Adjustable two ventilation slides control inner air / vapour circulation.
- Beaded heating elements made of high quality Nichrome/Kanthal wire are placed in ribs, at bottom and sides for uniform heat distribution.
- Inner chamber has ribs for placing the shelves at convenient levels. Supplied with 2 or 3 removable shelves.
- Temperature is controlled by electronic digital temperature indicator cum controller from 50°C to 250°C ± 1°C. fitted on the front panel for easy operations.
- Different programme functions can be designed for a wide variety of applications, and even when used
- Temperature is displayed by Digital LED with SV and PV display at front of the oven.
- Front Panel is provided with ON/OFF switch, temperature controller and indicators
- Supplied with cord and plug.
- Operating Voltage: 220 Volts AC (50 Hz).
OPTIONAL FEATURES OF OVEN UNIVERSAL DIGITAL
- Controlling of Temperature By Profile (Micro Programmable Controller)
- Audio Alarm System Activates at end of cycle Buzzer.
- Timer Facility Can be in built with Digital Electronic Timer
- Communication Port RS - 485 with Window based software
- PLC Based Control Systems With Touch Screen Display with Direct Thermal / Dot Matrix Printer.
- LCD Controller with Data Logger 16 x 2) with optional RS-485 communication ports, cables, window based software with inbuilt data recording.
