Universal - Model 3C-HYBRID -Compact Blower System

SHARE

Compact design for optimizing space while still keeping maintenance in mind. All enclosures suitable for outdoor installation with starting temperatures as low as -20° F, no space heaters required. (No additional cost).

Most popular related searches
blower
forced air
vibration isolation
oil drain
drain hose
noise control
blower system
compaction system
air cooler
  • A separate fan powers forced air ventilation which increases blower life, turndown range, and efficiencies by providing cooler air. Enables operation after shutdown to prevent heat spikes
  • Internal junction box for fan and additional single phase instrumentation options. Low cost option for single phase transformer for all instrumentations
  • Internal inlet vent boxes remove any direct line of noise for superior noise attenuation through engineered foam panel design
  • Extended oil drain hoses for easier changes
  • All maintenance with easy access from the front and back of enclosure for side-by-side installation
  • Auto-tension base designed specifically for your system to lessen corrections required by others’ auto-tension systems

YOUR PAIN

  • Wider variance in VFD turndown
  • Vibration issues and pipe resonance (lowering blower life and causing noise)
  • Blower failure due to heat
  • Extreme noise levei
  • Failures due to high temperature in enclosure

OUR SOLUTION

SAVES ON ENERGY
(due to wider temperature and RPM range)

LOWER PULSATIONS AND VIBRATIONS
(Screw Rotor has lower pressure differentials resulting in lower pulsations)

WIDER TEMPERATURE RANGE UP TO 350    F
(blower runs cooler due to more air movement across twisted impellers)

ENCLOSURE * LOWER PULSATIONS (as noted above) (will result in lowest noise levels for your operation)

ELECTRICAL FAN SEPARATED FROM MOTOR CONTROLS
(when blower is turned down it runs hotter, but our fan still moves air 3x - 4x faster per minute)

  • Internal Ilex joints provided with our systems maximize the prevention of vibration transmission
  • NEMA frame motors are standard to ensure domestic parts availability. (Competitors use IEC frame motors)
  • Vibration isolation mounts encased in metal for longer life and lower installation requirements
  • Forklift slots for easy installation of our "plug and play" design are covered when in place for superior attenuation
  • Unloading valve is not required. Superior construction materials in blower optimize efficiency, performance and life of your compressor. Our compressor can be started under full load to help line purging
