Universal - Model 3C-Pac -Compact Blower System
Compact design for optimizing space while still keeping maintenance in mind. All enclosures suitable for outdoor installation with starting temperatures as low as -20° F, no space heaters required. (No additional cost).
Most popular related searches
blower
forced air
vibration isolation
oil drain
drain hose
blower system
noise control
compaction system
absorptive silencer
air cooler
- A separate fan powers forced air ventilation which increases blower life, turndown range, and efficiencies by providing cooler air. Enables operation after shutdown to prevent heat spikes
- Internal junction box for fan and additional single phase instrumentation options. Low cost option for single phase transformer for all instrumentations
- Internal inlet vent boxes remove any direct line of noise for superior noise attenuation through engineered foam panel design
- Extended oil drain hoses for easier changes
- All maintenance with easy access from the front and back of enclosure for side-by-side installation
- Auto-tension base designed specifically for your system to lessen corrections required by others’ auto-tension systems
YOUR PAIN
- Limited options in meeting full performance range
- Limited options in instrumentation or controls to meet existing plant needs
- Equipment hard to service in compact design
- Extreme noise level
- Failures due to high temperature in enclosure
OUR SOLUTION
LARGEST SELECTION OF BLOWERS
(able to select based upon your entire range and budget)
FULL RANGE OF INSTRUMENTATION AND MANUFACTURERS
OPEN ENCLOSURE DESIGN WITH REMOVABLE DOORS
(for easy access to the front and back)
ENCLOSURE + HIGHEST QUALITY SILENCER
(absorptive + baffled for all frequency ranges)
ELECTRICAL FAN SEPARATED FROM MOTOR CONTROLS
(when blower is turned down it runs hotter, but our fan still moves air 3x - 4x faster per minute)
- Internal flex joints provided with our systems maximize the prevention of vibration transmission
- NEMA frame motors are standard to ensure domestic parts availability. (Competitors use IEC frame motors)
- Vibration isolation mounts encased in metal for longer life and lower installation requirements
- Forklift slots for easy installation of our “plug and play” design are covered when in place for superior attenuation
- Unloading valve is not required. Superior construction materials in blower optimize efficiency, performance and life of your compressor. Our compressor can be started under full load to help line purging
