Tanco - Model PLT-125 -Universal Oven
Double Walled Oven Universal (Memmert Type) is elegantly designed in various applications for microbiology, cell cultivation of animals and plants, food studies; general heating, drying, sterilizing, baking, to perform: material tests, ageing of computer chips, run complex experiments with highly sensitive loads, drying or tempering electronic components, hardening plastic resin. Our U universal oven stands for unparalleled precise, even and gentle temperature control. Double Walled Oven Universal (Memmert Type) is low cost options for heating- for various experiments in, industries, R&D labs, Pharmaceutical, Food & Beverage Industries and Institutions- in the field of Medical, Agricultural and Industrial Research.
- Outer chamber is made of Mild Steel duly powder coated.
- Inner chamber made of ALUMINIUM or STAINLESS STEEL (304) sheet.
- Forced convection system ensures good mixing, strong dispersion and maintains higher temperature uniformity inside the chamber.
- Thermal loss is prevented by filling mineral wool (Insulation) in space between the outer body & Inner chamber.
- Door Gasket fixed on the double walled door for proper sealing.
- Fitted with heavy hinges with a ball catcher, spring loaded door closing device. Door is duly insulated.
- Adjustable two ventilation slides control inner air / vapour circulation.
- Beaded heating elements made of high quality Nichrome/Kanthal wire are placed in ribs, at bottom and sides for uniform heat distribution.
- Inner chamber has ribs for placing the shelves at convenient levels. Supplied with 2 or 3 removable shelves.
- Temperature is controlled by capillary type thermostat from 50°C to 250°C ± 1°C. Temperature control knob is graduated in centigrade degrees
- Temperature is displayed on `L` shape thermometer fixed at front of the oven.
- Front Panel is provided with ON/OFF switch, thermostat control knob and indicators for mains and thermostats. Supplied with cord and plug.
- Operating Voltage: 220 Volts AC (50 Hz).
OPTIONAL FEATURES OF OVEN UNIVERSAL
- Air Circulation By F. H. P. motor fitted with blower
- Timer Facility By Mechanical Timer up to 2 Hours.
- Fan Speed Can be regulated by speed regulator.
