iCenta - Model Tracker 212 -Universal Process and Temperature Indicator

Features of the Tracker 212 universal process and temperature indicator include:

• Low cost with a 5 year warranty
• Quick and easy to configure
• Universal process or temperature measurement
• Accepts mV, mA, V, Ω Signals, type J, K, N, T, R, S thermocouples and PT100
• 24-point user linearisation for 4-20mA signals (tank contents applications)
• Sensor excitation for transducers (10V) or two wire transmitters (24V)
• Selectable degrees C or F for temperature sensors
• Display scaling to any engineering units for process inputs
• Max / min memory (requires front panel buttons)
• No internal pots, links or plug in cards
• Alarm relay fitted as standard
• Universal mains power input (110-250VAC)
• 12-32 VDC/VAC powered version option
• Scalable isolated analogue output option
• 2nd and 3rd alarm outputs option
• PC programming option

• Low cost with a 5 year warranty
• Quick and easy to configure
• Alarm relay fitted as standard

The Tracker 212 is a universal process and temperature indicator that supports the features and performance usually found in more expensive products.

Specification Detail of the Tracker 212 Process and Temperature Indicator:

• Display Type :
• 14.2mm high brightness red LED (green option) Range: 4 digit ( -1999 to 9999 )
• Update rate: 2 per second
• Material Body : Front panel – Protection to IP65
• A/D Converter Type :
• Dual slope integrating with auto zero
• Conversion rate: 100mS
• Common mode rejection: >150dB
• Series mode rejection: >70dB (50 & 60Hz)
• Thermocouple Inputs
• CJC accuracy: Better than 1°C after 30 minutes
• Open circuit sensor detection: Upscale
• Engineering units: °C or °F
• Measurement resolution: 1 or 0.1°C/°F
• Operating Temp Range : -10 to 70°C
• Humidity : 0-95% RH non condensing
• Outputs & Comms : 4 to 20mA
• Voltage & Current Inputs
• Ranges: ±20mA, ±100mV, ±10V DC.
• Scaling: Any portion of the display range (decimal point in any position)
• Accuracy: ±0.1% (worst case), 0.05% typical @ 25°C ambient
• Drift with temperature: <200ppm/ °C Impedance (Ohms):100M(mV), >1M(Volt)
• Approvals Safety
• EMC -Safety: EN61010 Susceptibility: EN50082-2
• Emissions: EN50081-1 CE Certified 2000
• EN61326 Immunity & Emissions (2001)
