UPT - Plano-Convex Lens
Positive focus length. Most suitable where one conjugate is more than five times the other, e.g. in sensor applications or for use with near collimated light. Also where both conjugates are on the same side of the lens, e.g. as an add-on lens to increase the numerical aperture.
Note for Lens:
- Lens made from materials such as N-BK7, Fused Silica, Sapphire, CaF2, Borofloat, or other optical glass supplied by Schott and Chinese CDGM are available upon request.
- Custom-made Lens at any size from Φ3.0mm to Φ200mm clear aperture are available. Besides round, Lens at shape of square are available.
- 90% clear aperture is available upon request.
- Better bevel is available upon request.
