Utile CeLPad - Evaporative Cooling System
When air contacts with water , water absords thermal energy from the air to evaporate. The result is the air temperature that will gone down. CeLPad amplifies and turns such a simple natural phenomenon into the most economical solution for providing optimal temperature and humidity. Made by specially-impregnated cellulose matrix. CeLpad rapidly absorbs water and provides massive contact surface between air and water. When hot and dry air passes through wet CeLPad, evaporative process takes place and the air is cooled down and humidified.
The more effective solution for evaporative cooling and humidification.
Very hot and very dry climates could have devastating effects on productivity of livestock productivity, plants, and humans. Evaporative cooling has proven to be one of the most reliable and economical methods to maintain optimum temperature and humidity.
CeLPad ( Cooling Pad ) is what you need for your evaporative cooling system to perform effectively and economically. When hot and dry air is induced through the wet CeLPad ( Cooling Pad ) , it will be cooled down and humidified. Our long experience in designing evaporative systems ensures that CeLPad ( Cooling Pad ) can make evaporative systems simpler and more efficient for you. Do not hesitate to contact us or your local distributor for more details.
CeLPad ( Cooling Pad ) has two basic configurations
- CeLPad ( Cooling Pad ) 0760 (45/15 flute angle configuration): Designed for minimizing pressure drop from the cooling pad. Suitable for the design with high air face velocity.
- CeLPad ( Cooling Pad ) 0790 (45/45 flute angle configuration): Designed for maximizing the evaporation efficiency by creating more contact time between air and water to allow for better evaporation. Suitable for typical application with a moderate air face velocity design such as poultry, and greenhouses.
** CeLPad ( Cooling Pad ) can be easily installed using PadPlus , a complete frame system .**
Maximum Efficiency : CeLPad ( Cooling Pad ) is designed to provide maximum contact surface between air and water (approximately 460 m2/m3). Such massive surface enables an optimum cooling and humidification effect from evaporation.
Maximum Freshness : CeLPad ( Cooling Pad ) acts as a natural filter that purifies inlet air. Carefully designed flute angle directs water towards both the air inlet and outlet side; the water then intrinsically flushes away dust, algae, and mineral build up on the evaporation surfaces.
Maximum Durability : CeLPad ( Cooling Pad ) is made of special cellulose paper impregnated with insoluble chemical compounds to preserve its long working life in your system.
Maximum Toughness : CeLPad ( Cooling Pad ), with proper water bleed-off and regular brushing, can be used in imperfect water and air condition.
