Swenson - Model MDV-SELECT Professional Series -V-Box Spreaders

FromSwenson Spreader LLC

SHARE

Designed for medium duty pickup and flatbed trucks. Ideal for use by municipality fleets, landscapers, and other contractors. Available in 8-, 9- and 10-foot hopper lengths. Available in hydraulic, dual motor electric, or gas drive options, with drag chain or belt over chain conveyor choices. More maintenance-free materials provide added strength and durability to protect against harsh weather and corrosive chemicals. Bolt-in replaceable floor is easy to maintain. Full length rubber chain shields eliminate leaking material.

Most popular related searches

chain belt conveyor

chain conveyor belt

landscape contractor

floor maintainer

Second chain wiper removes residual material on the drag chain bar flights.
Inverted-v moves center of gravity to the middle of the chassis, making the way the material moves safer.
Chain tensioner on the drive chain keeps constant tension on the spring eliminating frequent manual adjustments.
Tapered feedgate operates smoothly every time.
Light poly spinner has formed handles and quick pin connector for fast attachment and removal.
Coned center hub provides better balance, prevents material build up around the spinner shaft. Interrupted directional flights provides more consistent spreading.
Various spinner heights available to accommodate truck bed height.
Drop-n-Loc style sectional top screens are easier to remove and feature corner lift points for safer lifting. Recessed edges prevent interference from added accessories.
10-year warranty on poly idler assembly; 1 year on spreader

Size Specifications
- Length - 8, 9 and 10'
- Width - 70"
- Height - 46"
Capacity: 3.5 cu.yd., 4.0 cu.yd., 4.5 cu.yd.
Construction: Carbon or stainless steel
Drive
- Hydraulic
- Dual motor electric
- Gas engine – Honda or Briggs & Stratton
Conveyor
- Drag chain
- Belt-over-chain
Disk: 14” poly
Spread Width: Up to 30 feet
Top Screens: Drop-n-Loc sectional top screens
Warranty Details
- Poly idler assembly 10 years
- Spreader 1 year
Options
- Tarp kit, side extensions, vibrator kit, tie down kit, pre-wet kits
Materials
- Sand • Salt / Sand Mix • 3/8 Chips • Magnesium Chloride • Clear Path Ice Melt • Treated Rock Salt
