Zhejiang Vervo Valve Co., Ltd.
Vervo - Model ASTM A216 WCB -Axial Check Valve
Discover our ASTM A216 WCB Check Valve Plant featuring DN150, PN16, 6 Inch, Class 150 LB, and API 6D specifications. Made from carbon steel, this valve has EN 1092-1 flanged ends and an axial flow type design, ensuring durability and reliability for your industrial needs.
Most popular related searches
AXIAL Flow Check Valve, WCB, DN150, PN16.
Valve description:
- AXIAL Flow Check Valve, WCB, FLANGE.
- Design: API 6D.
- Body: ASTM A216 WCB
- Nominal size: DN150.
- Nominal class: PN16.
- End Connection: EN 1092-1.
- Face to face: EN 558-1.
- Test and inspection: API 598, DIN 3230.
Product Range:
- Body material: CARBBON STEEL.
- Normal diameter: 2-18 Inch (DN50 - DN450).
- End connection: BW, Flanged.
- Pressure range: Class 150 - 900 LB (PN16 - PN160).
- Working temperature: -29? - +425?.
- Product: AXIAL Check Valve.
- Nominal diameter: 2 Inch - 18 Inch.
- Design temp.: Down to -29?.
- Design pressure: Class 150 - 900 LB.
- Material: Carbon Steel.
- Design standard: API 6D.
- Face to face: EN 558-1.
- Connection end: BW, Flanged.
- Test standard: API 598, DIN 3230.
- Package: Plywood
- Application: water, oil and gas.
- SPRING: INCONEL X750, INCONEL 718
