Viatran - Model 386 -Pressure Transmitter
The Model 386 Flush Tip – Zero Cavity design offers an Isolated sensor assembly that virtually eliminates installation torque effect and is able to withstand pressure spikes up to 1.5x proof pressure and 5x burst pressure (or 30,000 PSI, whichever is less).
- Shunt Calibration circuit option
- All Stainless Steel construction
- RoHS Compliant
PERFORMANCE
Full Scale Pressure Ranges 0-100, 150, 160, 200, 300, 500, 750, 1000, 1500, 2000, 3000, 5000, 7500, 10,000 PSIG / PSIS
Static Error Band ≤±0.5% FSO (Includes BFSL, Hysteresis and Repeatability by RSS)
Compensated Temperature Range 70°F to 170°F (21°C to 77°C)
Operating Temperature Range -40°F to 185°F (-40°C to 85°C)
Storage Temperature Range -40°F to 250°F (-40°C to 120°C)
Long Term Stability (%FSO) ≤±0.25% FSO per 6 months
Thermal Effect on Zero ≤±2% FSO per 100°F Typical
Thermal Effect on Span ≤±2% FSO per 100°F Typical
MECHANICAL
Standard Pressure Port 1/2" NPT (M)
Zero Effect from Installation Proof Pressure 1.5x
Burst Pressure 5X (or 30,000 PSI, whichever is less)
MATERIALS OF CONSTRUCTION
Wetted Materials 15-5 PH and 304L Stainless Steel (Inconel 718 optional)
Weight 8 oz. nominal
