Great Wall - Model GZD -Vibrating Feeder

Vibrating feeder is used to transfer shaped and granule materials into receiving equipment from the hopper evenly, timely and continuously. It could feed the crusher continuously and classify the materials primarily in sand making and stone crushing line. It is widely used in industry of metallurgy, building materials, mining, chemical industry, beneficiation, etc.

Electric motor drives two engaged eccentric shafts to rotate through V-belt, thus generating the resultant linear excitation force, making the body vibrate compulsively on the supporting spring. Materials use the vibration as power to slide and throw in the material groove, thus making the materials move forward to achieve the purpose of feeding. When material passes through the screen bar in the chute, the smaller material can fall down through gap of the screen bar then to be screened.

1. Steady vibration, continuous and even feeding;
2. Pre-screening fine materials when feeding, so as to increase crushing efficiency;
3. Low noise and power consumption;
4. High working efficiency, large feeding capacity
