Metash - Model V-5000 -Visible Spectrophotometer
Latest Microprocessor Controlling System. Precision 1200 lines/mm Grating Monochromator. Easy Data Output by USB/Parallel Port. Wide Sample Chamber Enables Multi-functions. Four Display Modes; One-Button Quick Switching. (A/T/C/F).
- Brand: Metash
- Model: V-5000
- Minimum: 1
- Unit: Unit
- Pack: Hard Carton With Thick Foam Protected.
1. Latest Microprocessor Controlling System
One button auto zero calibration and 100%T calibration.
128*64 LCD display, direct readout of Transmittance, Absorbance and Concentration.
2. Precision 1200 lines/mm Grating Monochromator
Ensure high photometric resolution, high accuracy and low stray light.
3. Easy Data Output by USB/Parallel Port
USB Port: Connect to computer and operate through PC software. ( PC software is optional.)
Parallel Port: Connect to micro thermal printer to print test data. ( Micro thermal printer is optional.)
4. Wide Sample Chamber Enables Multi-functions
120mm wide sample chamber and long optical path monochromator provide enough space for optional accessories.
5. Four Display Modes; One-Button Quick Switching
Transmittance, Absorbance, Concentration and Factor (Coefficient) mode.
Model: V-5000
- Optical System: Single Beam, grating 1200 lines/mm
- Wavelength Range: 325-1000nm
- Spectral Bandwidth: 4nm
- Wavelength Accuracy: ±2nm
- Wavelength Repeatability: ≤0.5nm
- Wavelength Setting: Manually
- Photometric Accuracy: ±0.5%T
- Photometric Repeatability: ≤0.2%T
- Photometric Range: -0.3-3A, 0-200%T, 0-9999C
- Photometric Mode: T, A, C, F
- Stray Light: ≤0.2%Tat 360nm
- Display: 128*64 Dots LCD
- Detector: Silicon Photodiode
- Output: USB Port & Parallel Port
- Light Source: TungstenLamp
- Power Requirements: AC85~250V
