Vortex - Model 100-140 -Cast-Iron Submersible Pump for Sewage Water
Pump in cast-iron with "vortex" impeller. When the impeller turns, it creates a vortex pushing the water through the pump body. As the impeller is positioned in the upper part of the pump body it permits a wide free passage for the solid parts contained into the water. Thanks to its heavy duty construction and the top quality oil bathed motor the VORTEX 100 can be used also to pump sewage water and manure. In case an electrical problem occurs, the reparation of the pump is extremely easy because the electric connections and the capacitor are positioned under the cover and completely isolated from the motor; so if some water enters into the pump from a cut in the cable the motor will be safe.
The VORTEX 100 is usually installed into houses` cellars to drain the rain water or the domestic sewage water but it is also used in farms to pump out the dirty waters of the stables containing manure and solid parts. This model cannot be used to pump water containing stones.
- Max liquid temperature: 40 °C (104 °F)
- pH: 6-10
- Max density < 1100 kg/m³
- Max immersion depth: 5m
