C&D - Model UPS PLP -VRLA Pure Lead Plus Battery

SHARE

C&D Technologies’ UPS Pure Lead Plus batteries provide the same benefits from the High Rate Max Series plus the added benefits of C&D’s proprietary Pure Lead Plus Technology. Pure Lead Plus batteries provide superior performance and extended life at elevated ambient temperatures when endurance counts to ensure your business systems run uninterrupted.

Most popular related searches
lead battery
helium leak detection system
industrial process control
flame arrester
helium test
leak sealing
emergency response
laboratory testing
welding safety

Type:
VRLA Pure Lead Plus

Capacity:
300 - 1000 Watts Per Cell

Design Life:
12+ Years

Operating Environment:
Indoor
Outdoor Controlled
Outdoor Uncontrolled

  • 12+ year design life @ 25°C (77°F) with storage capability of 2 years at 25°C (77°F) with minimum upkeep
  • Standard warranty of 5 years at 25°C (77°F)
  • MSE’s Advanced proprietary paste processing for high active material utilization resulting in low float
  • Patented Long-Life Alloy in the grids to minimize grid growth, reduce gassing, and extend battery life
  • Available in both Top terminal and TFA (True Front Access) formats
  • Our TFA design maximizes energy density and minimizes internal resistance by providing a direct connection from the plates to the terminals
  • Published rates down to 1 minute
  • Patented UL Recognized Flame-arresting vents in each cell for safety
  • Thermally welded and helium leak tested case-to-cover bond ensures a robust leak proof seal
  • Can be operated in any orientation
Proprietary Technologies
  1. Pure Lead Plus with MSE Technology
  2. Fixed Orifice Pasting
  3. AGM Glass Mat Technology
Certifications & Compliances
  1. Not restricted for air transport – Complies with IATA/ICAO Special Provisions A67.
  2. Complies with UL1778, 924, 1989 AND 94 V-2, BS6290-4, IEC-896-2.
  3. UL-recognized component.
  1. Data Centers
  2. Network Operations Centers
  3. Industrial Process Control Facilities
  4. Internet Housing Sites
  5. Semiconductor Manufacturing
  6. Banks & Financial Markets
  7. Power Generation Plants
  8. Hospitals & Testing Laboratories
  9. Emergency 911 Response Centers
