Sani-Lav - Model 58W1 -Wall Mount Single Valve Wash-Station
Certified NSF/ANSI Standard 2 Food Equipment and NSF/ANSI 372 low-lead; Constructed from welded #16 gauge type 304 stainless steel. The front, bottom and back are formed from a single sheet with a rolled rim on front and sides. Exposed surfaces have a blended uniform satin finish. Specially designed knee valves provide easy access to working parts without disconnecting mount or plumbing.
(1) Four-person wall mount wash station – Model 58W1
(4) Single knee pedal valve (bottom mount) with 2 nuts – Model 112L
(4) Swivel gooseneck spout with aerator – Model 2003L
(2) Strainer assembly with basket – Model 1010
(3) Wall-mounting brackets – Model 1044
(3) Support brackets
(4) Connecting tubes for valve to spout connection – Model 1006L
(8) Fittings, brass, 0.375” male compression and 0.375” male NPT – Model 1008L
(4) Mixing check valve – Model 201L
Outside Dimensions: 80″ x 20″ x 18″ High
Inside Bowl Size: 77″ x 16-1/2″ x 8″ Deep
Back Splash Height: 10″
Water Activation: Single Knee Pedal Valve
Flow Rate: 2 GPM
Inlet Connections: 3/8″ Male Compression
Drain Opening: 2″
Finish: Satin
Strainer: 1-1/2″ Dia. Duo Basket Strainer
Wall Mounting Bracket: 1/4″ Dia. Mounting Holes
