Aquatec Oval - Model AT 30 to AT 225 -Wastewater Treatment Plants with Integrated Pumping Station
Wastewater treatment plants AT 30 oval iPS to AT 225 oval iPS are designed for decentralized and semi-centralized wastewater treatment solutions. They are intended for sewage sources of the size from 4.5 to 33.8 m3 / day. Supplied separately with integrated pumping station (iPS) with mechanical pre-treatment. The technological line can be extended with a sludge tank.
They are used for sewage treatment from blocks of houses, small villages, parts of a village, accommodation properties, restaurants, recreational properties, manufacturing factories, industrial parks. After preliminary purification of industrial wastewater with organic pollution the plants serve as biological treatment for meat processing factories, dairy factories and slaughterhouses, wineries, etc. Furthermore the treated wastewater can either discharge into the surface or underground water, respectively it can be reused for irrigation.
Integrated pumping station (iPS) in the tank of the wastewater treatment plant
- Volume 2,2 m3
- Mechanical pretreatment
- 3 floats (min., working, alarm)
- Possibility to install one or two pumps
- Pump error reporting via GSM
- 230 V pumps
- AQC iPS control unit
- Removable basket
The AT 30 oval iPS to AT 225 oval iPS wastewater treatment plants are ideally suited for conventional truck or container transportation.
The technology Vertical Flow Labyrinth – VFL®, used in the biological reactor, is protected internationally by patent. The treatment technology ensures the high quality of purified water, low investment and operation costs.
