Tanco - Model PLT-113 -Water Bath Incubator Shaker
Double Walled Water Bath Incubator Shaker (Desktop Model) is a versatile equipment to study on tissue metabolism, Enzymes and Protein Coagulation or other experiments requiring shaking of subject matter at constant speed under controlled temperature environment. Double Walled Water Bath Incubator Shaker is low cost options for Biotechnology, Clinical, Environmental, Micro Biology, Medical, or Industrial Applications.
Most popular related searches
water bath incubator shaker
water bath shaker
bath incubator
shaker incubator
bathing water
stainless steel tank
noise and vibration
digital temperature controller
incubator
temperature indicator
SALIENT FEATURES & CONSTRUCTION OF WATER BATH INCUBATOR SHAKER
- Double walled construction.
- Inner Tank and lid made of Stainless Steel (SS-304 grade).
- Outer chamber is made of Mild Steel duly powder coated.
- Heating by immersion heaters.
- Temperature range up to 900C.
- Controls temperature within an accuracy of ±1°C by microprocessor based digital temperature indicator cum controller.
- Thermal loss is prevented by filling mineral wool (Insulation) in space between the outer body & stainless steel tank.
- Shaking mechanism comprises of variable speed motor fixed on the left side and coupled to the oscillating tray riding on ball rollers oscillated through a geared variable speed motor. Tray shakes in linearly to and fro is with Minimum Noise and Vibration.
- Shaking motion of tray is controlled by speed regulator fitted at the panel.
- Fitted with PMDC heavy duty motor for continuous operation.
- Shaking tray can either hold test tubes or Erlenmeyer flasks of 25 ml or 50ml or 100 ml or 250 ml or 1000ml, as ordered by the user
- Supplied complete with one shaking tray as a standard accessory.
- Supplied with GABLED DOME LID for dripping of all condensate into the bath inside periphery.
- Fitted with THYRISTOR BASED DC DRIVE for speed range from 40 to 140 cycles per minute
- To work on 220/230V AC supply.
OPTIONAL FEATURES OF WATER BATH INCUBATOR SHAKER
- Temperature control by By profile (Micro Programmable) controller.
- Spare Shaking Tray With Lotus Clamp or Test Tube Rack
- Speed Indication By Digital RPM Indicator
- Communication Port with interface and data cable to download data to your PC
OPTIONAL FEATURES OF WATER BATH INCUBATOR SHAKER
- Applications same as of above but used where required (working temperature is below then ambient).
- Temperature Range 50C to 900C.
- Refrigeration is done by ISI Marked Compressor/Condensing Units CFC free & R-134 a eco friendly refrigerant.
