BIC - Water-Powered Pump
Water-Powered Pump is a hydraulic machine which can utilize the super-low head to generate energy to pump water automatically. The water-powered pump applies the surge pressure, which is produced by two check valves periodically opened and closed automatically because of intertia of moving water, to lift water to the higher elevation.
Most popular related searches
- The power is from the flowing water itself, operation cost is zero;
- The energy utilization rate is high, over75% at maximum. Currently, the total efficiency of the pump motor, made in China, with capacity below lOkw is lower than 55% generally;
- No attendant is required. The pump can operate continuously in year around;
- The moveable parts are the two valve clacks only, whose reliability is high and service life is long for decades. Besides the periodic replacement of sealing ring and spring, no repair is needed;
- No pump house and power supply facilities are required.
The water supply capacity of the water-powered pump is presented by the water supply volume in 24hrs, or the water supply discharge per day, m3/d.
The water-powered pump are applied to develop and utilize in high efficiency the super-low water head (0.5m<H
