SBM - Model LXMC -Wet Stirring Mill for Ultra Fine Powder Grinding
LXMC ultra fine wet stirring mill is a wet grinding mill plant developed by more than 30 years of grinding mill manufacturing experiences. With its flexible system in parallel or in series, it is capable of meeting the diversifed needs of the clients. The fineness can reach to 2 micron with 90% passing through rate per single mill one time.
- D90
- Capacity: 0.6-5 t/h
- Models: LXMC1000 LXMC3600 LXMC5600
Applicable materials: kaolin, coal-water slurry, mica, barite, ilite, gypsum, rare earth, magnesium oxide, aluminum oxide, red iron oxide, magnetic materials and So on.
Product features: Ultra fine powders, the finnest powders reach t o 2 micron with content 90% for milling one time.
The plant is widely used in grinding ground calcium carbonate(GCC), soft or hard kaolin, coal-water slurry, mica, barite, ilite, gypsum, rare earth, magnesium oxide, aluminum oxide, red iron oxide, magnetic materials and So on.
Products fineness up to micron grade and sub-micron grade.
Products can be directly used for paper filler, coating, or after drying for coatings, paints, cosmetics, disposable diapers, plastic, PVC, and rubber filler, wire and cable industries.
Homogenization slurry into the bottom of grinding chamber, transmission device drives multistage mixers motivation in multi dimensions and self rotation way, together with slurry and ceramic beads or zirconium beads.
The mixer tank is made by high resist abrasion with odd shape.
Materials are grind by weight and pressure of smooth surface balls and the stress of screw rotating centrifugal stress produced by friction, extrusion and shear, gentle rub and under the action of impact force, effectively.
Using the industrial teeth , said the mixer made of tungsten carbide alloy, reasonable linear velocity, can effectively reduce the starting torque, greatly reduce the wastage of the mill grinding meson balls, the pulp whiteness no effect;
Improve equipment operation efficiency and prolong the service life. The material properties does not change.
Wet stirring mill feed particle size is 200-400 mesh, largest single machine can grind 2 microns or less D90 (6000 mesh) of the following products; Optimization of the length to diameter ratio for pulp residence time is long, the material running route is long, high crushing ratio, uniform particle size distribution, particle shape is spherical.
- Widely used in many industries:
- Products can be directly used for paper filling, coating or after drying for coatings, paints, cosmetics, disposable diapers, plastic, PVC, and rubber filler wire and cable. Has a large output, high efficiency, low energy consumption, environmental protection and other features.
- High productivity, high grinding efficiency, low energy consumption
- Reliable and stable mechanical properties Vertical-shaped star wheel reducer higher transmission efficiency, run more smoothly
- Low consumption of grinding media, non-polluting; The temperature is low for finished products; Good liquidity
- The components inside the mill with high hardness wear-resistant materials, long service life
- Compact structure, suitable height, easy operation and maintenance, stable production, automatic controlling is optional
- Product standard : National Q/AEHM001-2010
- Overall dimensions : 2700mm (L ength) x2200mm (Width) x4500mm (Height )
- Motor : 132KW 380V
- Cooling method & Volume : Cooling and Flow: water C0ol 10M3/h (Recycle) ( recyclable )
- Feeding method : bottom side tangential feed
- Meson ball first installed capacity: about 1T (specific gravity 3.2)
- Equipment weight: about 7T without load, about 11T heavy load
