WHsensors - Wet/Wet Differential Pressure Sensor

The WH202 differential pressure (DP) transducer can measure line pressures up to 5,000 PSI with a turndown ratio of 15 to 1.

The WH202 contains no silicone oil, O-rings, or welds. This MEMS pressure sensor technology completely isolates the media to the pressure ports, thus eliminating contamination risk. The low strain level on the diaphragm results in accurate, repeatable measurements. The WH202 can be used to measure differential pressure across a filter, monitor level in a sealed or vented tank, or calculate flow across an orifice plate.

With its digital compensation, this series offers excellent linearity and performance over temperature. The electronics now offer a fail safe condition on the output signal. If the transducer were to experience a fault condition, the transducer can be programmed to rail the output signal to 10% below the minimum or 10% above maximum output signal to notify the user of an issue and protect the system from undesirable conditions. The WH202 also offers excellent flexibility in its configuration, allowing for a variety of
sensor materials and pressure ports.
