WHsensors - Model WH 131-PT -High Accuracy Precision Pressure Transmitter/transducer

The  WH131-PT Series digital/confi gurable (an industry fi rst) industrial pressure transducer features excellent stability and precision accuracy over a wide temperature range at lower cost than competitive units. With its proprietary digital technology, the  WH131-PT Series features fi eld proven redundant sensing elements without the need for solder in resistors or trim pots that can drift over time. This provides years of excellent performance and reliability even in the harshest/demanding applications. This combined with the optional integrated temperature or pressure digital switch feature, makes the  WH131-PT Series truly an industry fi rst and second to none.

• Accuracy at highest pressures (for example, with an accuracy class of 0.25 at 2,000 bar).
• Totally digital proprietary design
• Innovative redundent sensing elements
• 24V digital output for pressure or temp switch point
• Variety of voltage outputs available
• Custom pressure Ranges and outputs available
• More standard pressure ranges, Industry First
• 2x overpressure rating

• Aerospace Hydraulic and Pneumatic Pressure Systems
• Analytical Instruments
• Hydraulic Pressure Equipment
• Hydrogen Pressure (Consult factory for media compatibility)
• Laboratory / Metrology Equipment
• Medical
• Military Vehicles
• Test Stands
