WIMMER - Model AB 1300 -Lightweight Drilling Carriage

Super-lightweight universal carriage for use with >8 t excavators. 360° rotate, 90° swivel, all drilling positions are possible. Standard: Automatic empty hammer, cavity safety device, anti-fixed drilling device and soft drilling - to protect drilling steel and drill bits. Lightweight, stable high-performance profile as standard. Own power supply, no electr. connections required. Radio remote control as standard, drilling functions proportionally controlled. Efficient percussion drilling up to 63 mm. Rotary drilling / downhole drilling up to 135 mm. Anchor drilling with injection up to 89 mm. Wimmer Cockpit Drilling Data Analysis.
