FY-XL - Model 12-3/4" -wire wrapped screen pipe
wire wrapped screen pipe Benefits of the Wedge Wire Screen 1. Maximum Flow Rate The slots are arranged in a uniform pattern, allowing water to enter the screen directly from all directions of the water bearing area. 2. Excellent Sand Control Performance Traditional perforated tubes have holes large than 1 cm, which do not keep sand out. Scratches and corrosion on the outer wrap layers leads to more sand, gravel and clay entering the well pipe, which in turn leads to clogging. However, the wedge wire screen has slot openings between 0.5mm and 1.5mm, keeping most sand and abrasive particles out. 3. Long Well Life Each wedge wire screen undergoes anti-corrosion treatments, rendering it less prone to rust or encrustation. 4. Easy Installation Wedge wire screens are lighter than cast iron pipes or perforated tubes, making them easier to install. 5. Standard Length The standard length of each wedge wire screen is 3.2m. Pup joints can be added upon request.
water well screen, perfect roundness screen tube, profile wire screen pipe, wedge wire screen, wire wrapped screen, screen tube, screen pipe, sand control well screen, oil well screen, v wire slot screen, rod based continuous slot screen, wire wound stainless steel screen pipe, johnson well screens
Product Advantages of Johnson Well Screen Pipe:
1. Anti-Corrosion Sand Control Johnson Well Screen Pipe With Threaded for Groundwater
2. Selling point: High Strength, Anti-Corrosion, Easy Installation, Anti-Pressure, Rust resistant
3. Surface treatment: Pickling and polishing, Bright
4. Diameter: 2-1/2", 3", 4-1/2", 4-3/4", 6-5/8", 8-5/8", 10-3/4", 12-3/4", 14", 16",18", 20"
5. Slot size: 0.1mm, 0.2mm, 0.3mm, 0.4mm,0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm in usual, also can be others.
6. Length: 1m, 2m, 3m,10ft, 4m, 5m, 5.85m, 20ft (2.9m/2.95m, or 5.8m / 5.85mto fit container)
7. End connection: Plain beveled ends for butt welding, male/female threaded,Flange, Closed Up etc.
8. Material: Low Carbon, Low Carbon Galvanized steel (LCG),Stainless Steel( 304,etc.), Duplex Stainless Steel, 904L etc.
9. Well deep: v / wedge wire: 2.5x4mm Well deep: 200-300m,
v / wedge wire: 3x4.6mm Well deep: 350-450m
v / wedge wire: 3.3x6.5mm Well deep: 500-650m
