Firsa - Model 150LBS - FIG. 141 -Y Type Strainer

Design according to ANSI B 16.34. Full range of body and screen materials. Bolted cover. Flanges according to ANSI B 16.5 from 2` to 24` Flanges according to ANSI B 16.47 from 26` Bw ends according to ANSI B 16.25 Face to face according to ANSI B 16.10 Standard screen perforation 1,5 mm round holes other perforation or wire cloth available on request. Rabot btween filtering area and piping section minimum S  Testi ng accordi ng to API 598, BS EN ISO 12266 PART 1.
