Yumizen - Model H500 -Open Tube (OT) & Closed Tube (CT)

• Rapid Testing
• Only 3 reagents use for Diff analysis
• Whole blood 20 µL sampling
• 27 parameters
• Flags & alarms expert system
• Proven technologies of impedance and optical detection

Technical

• Weight: 23 kg / 51 lbs
• Power supply: 100 to 240 V (± 10%), 50 to 60 Hz
• Dimensions: 48 cm x 40 cm x 48 cm / 16 x 19 x 19 in
• Printer: Compatible models with Linux drivers
• Throughput: Approximately 50 tests / hour
• Screen: Colour LCD touch screen of 12.1 in
• Data management:
• Linux
• Transmit patient & QC to LIS
• Uni-directional or bi-directional connection
• Communication Protocol: ASTM
• Connection: RS232, Ethernet, USB
• Memory: 10,000 results + Graphics
• Quality Control Management:
• 3 controls levels (low, normal, high)
• Target values download (USB)
• Levey-Jennings Graphs
• Radar Graphs
• XB on 3 or 9 parameters, mean of 20 runs
• Compatible with QCP
• Logs: Reagents, calibration, Quality Control, blank cycle, users, settings, service, communication

Samples

• Parameters (27): WBC, NEU# & NEU%, LYM# & LYM%, MON# & MON%, EOS# & EOS%, BAS# & BAS%, LIC# & LIC%*, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD*, PLT, MPV, PCT*, PDW*, P-LCC*, P-LCR*
• Graphics: High-definition Diff matrix PLT, RBC curves
• Sample-Volume:
• CBC mode: 20 µL
• DIFF mode: 20 µL
• Stability: 48 hours post-draw stability for CBC parameters, 24 hours post-draw stability for DIFF parameters
• Operating sample mode: Open or Closed Tube
• Identification: Alphanumeric. Bar-code reader (optional)

* RUO (Research Use Only)
