ZOGLAB - Model Mini-T -Data Logger for Temperature
Large-screen display of temperature and humidity, with battery, memory, recording status show together. High precision, mass memory for long-term logging. Free of toxicity and halogen as FDA / HACCP / ISO22000 require. Resistant to water and dust, suitable for cold chain systems of fresh food, fruit, vegetables or wine. Available MINI data logger with no LCD, for more redundant working temperature.
Most popular related searches
data logger
cold chain system
environmental instrument
flame retardant
environmental data logger
HACCP
process monitoring
environmental data
temperature logger
temperature monitoring
Measuring Data
- T Measuring Range: -30?~70?,-40?~85?(No display)
- T Accuracy: ±0.5?, ±0.3?(High-precision version)
- T Resolution: 0.1?/0.2?
General
- Memory Size: 30,000 / 60,000 units
- Alarm: High level and low level , Display+beep+backlight , support alarm mark
- Sampling Interval: 2s?5s?10s?30s?60s?255s
- Logging Interval: 2seconds~24hours
- Start with Delay Time: 1~120s
- Start Mode: Key operation(software could be customized) / Start immediately / Time-lapse start / Timing start
- End mode: Key operation(software could be customized) / Full / FIFO / Presetting units / Timing end
- Timing Start / End: Random start / End with format YYMMDD HHMMSS
- Storage Temperature: -50?~90?
- ESD Protection: ±25KV
- Interface: Mini USB 2.0
- Battery: 3.6V lithium battery ×1(Rechargeable)
- Battery Lifetime: 1 year (with a sample rate of 60 seconds)
- Software: ANALYSIS 3
- IP Class: IP64
Sensing Probe
- Model: Internal
General Feature
- Dimensions: 86.2×64.2×25.4mm
- Display Area: 41×30mm
- Housing: ABS+PC,flame-retardant,toxicity and halogen free
- Weight: 84g
