Dewatering Analysis Services
For a lab dewatering analysis of your material, print and complete the Sample Data Sheet and attach it to the 5-gallon sample or fax it in advance. In regards to the sample please make sure the consistency is above 4% solids. In order to have enough solids to run an adequate dryness test, we can always dilute if needed.
Most popular related searches
pipe flange
flanged pipe
screw press
dewatering
drum thickener
dewatering service
discharge pipe
laboratory analysis
thickener
IDT-200 Internal Drum Thickener
- Weight - 4,500 lbs
- Dimensions - 68" X 67" X 179"
- Capacity - up to 250 GPM (depends on freeness of material)
- Power - 460/480 VAC 60 Hz @ 15 amps
- Shower Water - 15 GPM @ 40 psi (1-1/4" Female inlet threaded pipe)
- Inlet Flange - 4" pipe flange
- Filtrate Discharge Flange - 6" pipe flange
Model 08L200 Screw Press
- Weight - 5,000 lbs
- Dimensions - 33" X 28" X 172"
- Capacity - 1-18 bdt/day @ a minimum of 4% solids
- Power - 460/480 VAC 60 Hz @ 20 amps
- Air - 1/4" air line 80-120 psi 0.5 - 1 cfm
- Filtrate Discharge Flange - 8" pipe flange
