We are happy to put our comprehensive machine park for the mechanical processing of larger and more complex parts as well as our welders and machine fitters at your disposal for completing contracts. With our mostly CNC controlled machines, we can process tools of up to 4m diameter, 2.5m in height and 15 tonnes in weight with up to 6 axis. We also possess a machine for dynamical balancing and a sand blasting machine. Our welding methods include WIG, MIG and MAG for standard and stainless steels. For further information, contact Werner Braun our head of production.

Most popular related searches

Our machine park includes
5-Axis Machining Center DMU 200:

  • Processing: turn, drill and mill
  • Diameter of rotary disk: 1850 mm
  • Axis moving space: X-axis: 1800 mm
  • Y-axis: 2000 mm
  • Z-axis: 1100 mm
  • Max. work piece weight: 5000 kg

Carousel turning machine MS 43/CNC/MSF-2:

  • Processing: turn, drill and mill
  • Face plate diameter: 4000 mm
  • Max. turning diameter: 4300 mm
  • Max. work piece height: 2275 mm
  • Max. work piece weight: 15000 kg

CTX gamma 2000 TC:

  • combined 5-axis lapping-milling center
  • with x = 2.050 mm and y = 700 mm
