FAB - Fabrication Service
The FAB 3R team is able to meet the most stringent welding requests. Certified for ASME, CWB, UStamp, RStamp, and PED, the team uses the most suitable type of welding for your large-sized equipment. The FAB 3R team masters mild and exotic steel welding, and is also skilled in welding on pressure equipment. FAB 3R also offers a range of non-destructive tests to make sure the equipment meets the specifications and the strictest standards. With a surface area of over 97,000 square feet (9,000 m2), our fabrication shop is able to do several-month welding jobs on large and very large equipment.
WELDING PROCESSES
- FCAW, GTAW, SMAW, GMAW, SAW
MATERIALS
- Steel : A36, A516, 44W
- Stainless steel : 300 series, Duplex
- Exotic steel : Super-Duplex (2101, 2205, 2507), 6-7% Moly
NON-DESTRUCTIVE TESTING
Fabrication operations are rigorously controlled by ONGC-Level 2-certified inspectors :
- Dye penetrant
- Magnetic particles
- Ultrasonic
- X-rays
MAXIMUM CAPACITIES
- Submerged arc: 20 ft x 20 ft (6 m x 6 m)
- Positioners: 12 tons (11,000 kg)
- Shear press: 0.5 in thick x 14 ft wide (1.27 cm x 4.2 m)
- Press brake: 10 ft x 14 ft (3.1 m x 4.2 m)
- Roll forming: 1.25 in thick x 8.5 ft (3.18 cm x 2.6 m)
- Max height under hook: 31 ft (9.5 m)
- Width and height of doors: 32 ft x 32 ft (9.75 m x 9.75 m)
