Glass Grinding and Cutting Services

SHARE
UQG Optics specializes in offering comprehensive glass and optical machining services to meet diverse requirements from simple to highly complex projects. Their expertise includes precision grinding and cutting, tailored precisely to achieve specified dimensions for both custom and stock optical components. They handle a variety of materials such as optical and technical glasses, fused silica, quartz, BK7, borosilicate, sapphire, silicon, ceramic, and many more. Advanced machining services include CNC surface grinding, diamond sawing, annular ID sawing, cylindrical grinding, waterjet cutting, glass scribing, bevelling, chamfering, drilling, milling, and sand blasting. Each of these processes is designed to meet exacting tolerances, ensuring precision and quality. For micro dicing needs, their precision dicing services provide detailed solutions. Contract services are available for customer-supplied materials and components, emphasizing versatility and precision in all tasks. UQG Optics also offers related services like optical assembly, polishing, lapping, and custom optical components.
Most popular related searches
custom optical component
metal cutting blade
stack filter
water jetting
cutting mill

UQG Optics offers glass and optical machining services on customer materials and components. Jobs can range from simple tasks such as cutting a piece of float glass in half to more complex tasks such as cylindrically grinding quartz rods to tolerances of 0.01mm.

We can undertake precision grinding and cutting of one-off custom or stock optical components to achieve specific dimensions, as well as contract production.

Contract work is undertaken to customer-supplied components and materials.

Machine services offered include the following:

CNC surface grinding
Reducing bulk glass surfaces to a surface finish of 50 microns. Grinding tolerance to ± 0.05.

CNC surface grinding
Reducing bulk glass surfaces to a surface finish of 50 microns. Grinding tolerance to ± 0.05.

CNC (diamond) sawing
Diamond sawing squares and rectangles from sheet glasses and optical materials to a cutting depth of 100mm. Cutting tolerance to ± 0.20mm.

Annular ID sawing
Precision ID slicing of substrates, wafers and components up to 100mm diameter. Cutting tolerance to ± 0.05mm.

Cylindrical grinding
OD grinding of rods and tubes or stack edging filters. Diameters 5mm to 250mm. Grinding tolerance to ± 0.01mm.

Waterjet cutting
Waterjet cutting is ideal for achieving shapes and complex designs, glass rings, and cutting technical sheets and glasses. It’s is also used to cut AR coated sheets and quartz sheet leaving a ground edge with no tooling costs. Cutting tolerance to ± 0.10mm.

Glass scribing
The slicing scribe & break process uses CNC multi- or single-blade cutting wheels and is ideal for ultra-thin glass and coated glass sheets. Additional working such as bevelling can be applied after cutting. Cutting tolerance to ± 0.1mm.

Bevelling and chamfering
Sharp edges and corners can be ground using our bevelling and chamfering process to a uniform size and angle. This is ideal to accommodate housings, for protection of assembly operators and protection of components.

Glass drilling
Diamond drilling and trepanning holes, cylinders and discs. Holes are drilled to a minimum of 2mm diameter, or for smaller sizes laser or ultrasonic drilling is recommended. Drilling tolerance to ± 0.05.

Milling
CNC milling to cut outs, strips and recesses around the edges of squares and rectangles. Grinding tolerance to ± 0.05.

Diffusing & sand blasting
Faces and surfaces can be diffused by either fine alumina or grinding grit. We offer a range of sand blasting grades ranging from from 10 microns to 100 microns.
