Introduction for V Wire-Wrapped Welding Screen Tubes

1.  V Wire-Wrapped Welding Screen Tubes Materaial

We use normally 304 304L  316  321 and 316L S.S.  Or according to customers' require.

2.  V Wire-Wrapped Welding Screen Tubes Construction

Our filter elements were welded by profile wire and support wire. We can make the screens in different shape according to the different usage. Like tube and plate etc.

We use wedge-shaped frofile wire in order to make the slot v-shaped. It can stop the impurities very well.
The wedge wire was welded on the support wire well-proprtioned andhave perfect roundness. Ensure the screen have bigger filter area and non obstructive, avoid the high concentration of impurities.
After wok for a period of time, the filter can be back flush. It can use for many times.

3.  V Wire-Wrapped Welding Screen Tubes Flow Type

From outside to inside (FOTI)
from inside to outside(FITO)

4. Type of profile wire and support wire

Profile Wire of Perfect Roundness Wedge Wire Screen Pipe

Profile Wire      Width         Height          Material

10SR             0.75mm      1.5mm      304 316 316L,etc

12SR             1.0mm        2.0mm      304 316 316L,etc

18SR             1.5mm        2.9mm      304 316 316L,etc
​

Support Wire of Perfect Roundness Water Well Screen Pipe

Profile Wire     Width       Height         Material

Q22              2.0mm      2.3mm    304 316 316L,etc

Q25              2.0mm      3.0mm    304 316 316L,etc

5 .  V Wire-Wrapped Welding Screen Tubes Product Instruction

V Wire-Wrapped Welding Screen Tubes Struction: Xinlu company Slot tubes widely used in beverage / beer filtration, papermaking industry, industrial waste water treatment, oil, water desalination, etc. This slot tube is the most widely used in all kinds of filter screens.
