Spectra Analysis - Version DiscovIR10 -Fully Interactive and Intuitive System

Operating system

• Microsoft Windows 10; 32 or 64 bit
• Microsoft Excel is needed to modify or create report templates
• Dedicated Ethernet port for DiscovIR system (Needed for full license only)

Standard Features:

• Real-time  data collection and post-run RT rescan
• Chromatographic / spectral workup
• Band chromatograms for chemical classes
• Unattended operation
• Directly controls DANI Master GC
• Alignment and tuning tools

New with DiscovIR10^TM Software:

• Process data, create reports, and edit sequence while running samples
• Customize report contents and format easily using report generator templates
• Edit sequence of future runs while collecting data
• Improved Spectral Quality
  • “True Spectra” displayed with flat baselines – unknowns look like the libraries
  • Removes chromatographic drift by using local backgrounds
• Chromatogram with spectra displays include Topographic map
• Estimate amount of Liquid Nitrogen for the sequence of analysis
• DiscovIR10 allows 16+ hours of unattended operation with customized hardware
• Autonomous Operation Mode– No Sequence Editing, DiscovIR10 collects whenever the GC or GCMS injects (coming soon)

Library Search Includes:

• Analytical Spectra visually match the library Spectra
• 100% quality match scale
• Spectra compatible with all ATR and transmission solid phase FTIR Libraries
• Displays Chemical Structures
• Chromatographic retention time matching using Linear Retention Indexes (LRI)
• Create encrypted libraries

Software interactions:

• Ribbon style graphic organization
• Interactive workspace tabs
• Workflow guided by icon sequence
• Hierarchical privilege level access

What you can do:

• GC Mass Spectrometers directly couple to DiscovIR systems
  • Autonomous Operation Mode – no need to prepare multiple sequences and have them synchronized
• Modes of Operation:
  • Edit sequence in DiscovIR10 and have it run the integrated Dani Master GC
  • Edit sequence in DiscovIR10 and export as a csv file to be imported by other GCs
  • Run DiscovIR10 autonomously without a sequence by using the start and stop commands sent by the GC (coming soon)
