OmniDriver - Ocean Premier Device Driver Platform Software

OmniDriver is available for both 32- and 64-bit versions of Windows (XP/7/8), Linux (32/64-bit), and MacOS X.  OmniDriver can be called from Java (via OmniDriver.jar), .NET languages including C# and Visual Basic .NET (via NETOmniDriver.DLL), C/C++ (via DLL, .so, and .dylib respectively).  Other .NET-capable frameworks like LabVIEW are also supported, as are tools supporting Java .jars (MATLAB).

Sample code is provided for various languages at the following links.  You can also download a full Sample Pack of OmniDriver samples written for these and other languages, and many compiler versions.

• Java samples
• C# samples
• Visual Basic .NET samples
• Visual Basic 6 (COM) samples
• LabVIEW 2012 samples
• Delphi samples
• Excel samples

Using OmniDriver, you can do these and more on supporting spectrometers:

• read spectrometer model and serial number
• set integration time, scan averaging and boxcar
• read spectra (intensity and wavelengths)
• read and write calibration coefficients (wavelength and linearity)
• configure corrections for electrical dark, linearity and stray light
• set trigger modes
• set single and continuous strobe options
• read bench, grating, and detector settings
• control data buffering
• command attached light sources
• configure thermal-electric cooling
• read and set GPIO pins
• load and save irradiance calibration
