Securiton NetSoft - Centralized Visualization and Operation Software for Aspirating Smoke Detectors

SHARE
NetSoft is a sophisticated software solution designed to provide clear and centralized visualization and operation capabilities for aspirating smoke detectors (ASDs). It allows users to monitor live data from all connected ASDs via a single interface, enhancing operational efficiency and situational awareness. A building plan can be imported into the software, allowing users to visualize the precise location of each detector. Alarms, malfunctions, and other system states are depicted with distinct colors, ensuring swift identification and response. In addition, NetSoft supports trend analysis by visualizing measurement data, enabling comparison between different ASDs. Access and configuration are simplified through a user-friendly interface that permits remote parameterization, leveraging the robust RS-485 bus for network connectivity. The platform supports access from multiple locations and provides an easy integration with the ASD Config tool for comprehensive configuration tasks.
Most popular related searches
aspirating smoke detector
smoke detection system
fire detection system
color measurement data
fire detection
color measurement
data visualization

NetSoft: visualisation and operation from a central point

Your advantages of Netsoft:
  • SecuriSmoke ASD visualisation
  • One UMS server and up to 3 clients
  • Display of measurement data as a trend diagram
  • Colour state display of devices on the building plan
  • Spatial resolution with REK 511
  • Configuration directly from the user interface

NetSoft offers clear visualisation of live data of all connected aspirating smoke detectors. One central display offers an overview of all the states of the connected devices. A building plan can be imported into NetSoft for better visualisation of the location. Alarms, malfunctions and other states are distinguishable by their colour. The measurement data can also be visualised as clear trend graphics, for example to compare ASDs with each other.

Thanks to the clear visualisation, operation of ASD devices connected to NetSoft is simple. Has a detector state changed, as indicated by a change of colour on the NetSoft user interface? If so, you can access the device via the visualisation and see the values being measured in real time on the ASD. Networked ASDs can be accessed from up to three different locations (clients).

Do you want to change the alarm threshold of an aspirating smoke detector? Or perform a different configuration? Thanks to NetSoft, this has never been easier for technicians, who can access all connected devices via the user interface and carry out a complete parameterisation. Selecting a device opens the easy-to-use ASD Config software tool, which is used to configure the selected ASD from a remote location.



SecuriSmoke aspirating smoke detectors are connected to NetSoft at the field level by means of stub networking via the robust RS-485 bus. To obtain a more accurate location of the smoke source, up to four REK 511 units can be connected to an ASD 535 and visualised by NetSoft.
