Diesel Air Filter Cleaning

HOW THE GREEN FILTER CLEANING MACHINE WORKS Easy to load, automatic and programmable cleaning cycles, filters cleaned in 3 to 5 minutes. Dry compressed air cleans filters from the inside out. Pollutant dust is safely captured with our powerful cyclone collector than safely stored in a supplied 55gal drum. Filter Inspection Station available, recommended for air intake filters used in Diesel Engines, measure restriction levels of air filters to confirm filters integrity Filter Inner Diameter: 6.5` Minimum for inner Diameter Filter Outer Diameter: 20` Maximum for outer Diameter Filter Height: Up to 32` High – closed one end or open at both ends (Other sizes Available – Contact Mfg. For Details) Injection Cleaning System HOW THE INJECTION SELF-CLEANING SYSTEM (ICS) WORKS The Injection Self-Cleaning System releases compressed shop air through a rotating air jet that is driven up and down in a spiral motion inside the filter cartridge. In order to maintain the cabinet clean, an air pu
