A-Lok Products, Inc. products

The A-LOK Premium is a flexible compression connector which will provide a guaranteed watertight seal between the pipe and the wall of a concrete structure. The A-LOK Premium is manufactured to meet or exceed all material and test requirements set forth in ASTM C-923, ASTM C-1478 and ASTM F-2510. A-LOK Premium instantaneously reacts and redistributes its viscoelastic dynamic core material to maintain its circumferential sealing pressure. The core of the connector is filled with a blend of materials which provides a controllable and dynamic viscose fluid within the connector. This material will remain equally distributed throughout the core of the connector, so in the event of short-term or long-term settlement of the pipe begins to occur, the core material will react by redistributing and equalizing the blended materials to maintain its proper sealing compression.

The A-LOK X-CEL flexible pipe-to-manhole connector was designed to produce a guaranteed watertight seal between a pipe and a concrete structure. Performance watertight connector for wastewater, storm, and light industrial demand ranging in size from 4 ¼ ` to 102`. Designed to meet ASTM C-923, ASTM C-1478 and ASTM C-1644 standards.

The A-LOK STM is a flexible pipe-to-manhole connector designed for the prevention of soil and water infiltration into stormwater sewer systems. This minimizes the chance of pothole formation and sediment build-up in the storm system, saving states and municipalities money over the life of the structure. It can be used with round, elliptical and arch shaped pipes for curved and flat wall structures. The A-LOK STM was designed to meet or exceed the ASTM C-1478 standards.

The INSERTA-LOK is a flexible pipe-to-manhole connectors specifically engineered to produce a positive watertight seal for pipes entering precast concrete structures and the structure itself. The INSERTA-LOK Connector is manufactured to meet or exceed the requirements set forth in ASTM C-923 and ASTM C-1478.

The Z-LOK Connector is a flexible pipe to manhole connector specifically engineered to produce a positive watertight seal for pipes entering precast concrete structures and the structure itself. The Z-LOK Connector is manufactured to meet or exceed all material and test requirements set forth in ASTM C-923, ASTM C-1478, ASTM C-1644 and ASTM F-2510.

The QUIK-LOK BOOT CONNECTOR is a flexible pipe-to-manhole connector specifically engineered to produce a positive watertight seal for pipes entering precast concrete structures and the structure itself. The QUIK-LOK CONNECTOR is manufactured to meet or exceed all material and test requirements set forth in ASTM C-923, ASTM C-1478, ASTM C-1644 and ASTM F-2510.

The Z-LOK STM Connector was designed to address the need for a boot style connector for large diameter pipe, making it ideally suited for stormwater application. Available for 6`-102` pipes. A watertight connection is produced by tightening the Redi-LOK Clamp to the specified torque value. The Z-LOK STM Connector is manufactured to meet or exceed all material and test requirements set forth in ASTM C-923, ASTM C-1478 and ASTM F-2510.

The revolutionary G3 BOOT SYSTEM makes installation into a structure simple and fast. Just install the connector perpendicular to the hole and tighten the stainless steel nut. As the nut is tightened, a compressive force is applied to the G3 band ends, causing the ends to slide past each other into straight alignment. This movement increases the bands overall circumference and compresses the connector against the opening in the structure wall, creating a watertight seal. To ensure the best seal, place the bolt in the 12 o’clock position of the hole opening and tighten the nut to the specified torque value.

Let AïLOK Products, the recognized leader in the manufacturer of watertight connectors, show you profitable, cost-effective septic connectors that work!
