ADS Pipe Canada products

This specification covers the general requirements of corrugated high density polyethylene pipe for use in roadway subdrain and related construction applications.

This specification covers the general requirements of corrugated high density polyethylene pipe (HDPE) with a smooth interior for use in culverts, municipal drainage and related engineering applications.

This specification covers the general requirements of corrugated high density polyethylene (HDPE) pipe with a smooth interior for use in storm sewer and engineered projects requiring leak-resistant joints.

This specification covers the general requirements of corrugated High Density Polyethylene (HDPE) drainage tubing for use in various land drainage applications.

This specification covers the general requirements of spiral wound high density polyethylene (HDPE) profile pipe with smooth outer and inner walls specifically designed for in-place relining of underground culverts.

N-12® pipe is the world standard for corrugated polyethylene drainage pipe. Introduced in 1987, N-12 dual wall pipe with its smooth interior wall and corrugated exterior wall, offers exceptional hydraulics and strength. Built using application specific high-density polyethylene, N-12 corrugated pipe also provides superior corrosion and abrasion resistance making it an excellent alternative to reinforced concrete and corrugated metal pipe. These properties have led to the increasing approval and acceptance of N-12 drainage pipe in storm water applications.

N-12 corrugated dual wall pipe was introduced in 1987 and offers significant performance advantages. Available in diameters from 100 - 1500 mm (4” - 60”) N-12 pipe is replacing traditional materials as a preferred product. The development of large diameter pipe is only one example of Ideal Pipe’s commitment to providing superior products and improved performance. Our HDPE pipe delivers superior value, while providing physical strength and structural design that cannot be matched by traditional materials.

N-12 WT IB (per CSA B182.8) pipe has set the standard in watertight performance for corrugated polyethylene pipe. N-12 WT IB pipe is a gravity flow, watertight pipe, which is available in a complete range of sizes from 100 - 1500 mm (4”-60”) diameters. The pipe is third party verified to meet 74 kPa (10.8 psi) laboratory pressure and vacuum testing requirements. N-12 WT IB pipe (per CSA B182.8) incorporates patented technology to provide a superior watertight joint. An exterior bell wrap provides a quick visual indicator to customers and inspectors that a watertight product is being used. A patented gasket increases its sealing forces as intermittent internal or external hydrostatic pressure occurs. The flared bell and spigot significantaly improves ease of installation. These advanced joint design features reduce infiltration and exfiltration, resulting in outstanding long-term performance.

N-12 corrugated dual wall pipe was introduced in 1987 and today’s N-12 ST IB pipe offers significant performance advantages, plus the best soil tight joint in the industry. Available in diameters from 100 - 1500 mm (4” - 60”), N-12 pipe is replacing traditional materials as a preferred product for storm water applications. N-12 ST IB pipe contains a superior built-in bell and spigot joint. The joints are sealed by high-quality, factory-installed gaskets that meet all the requirements of ASTM F477.
