Aqualitec Corp. products

The Altec flotation unit is designed to treat wastewater with high solids loading. The capacity of the Alpha unit ranges from 5 m3/h up to 200m3/h. The Altec serie is designed to create the optimal circumstances for easy separation of the solids. The large free surface area and long retention time guarantee an optimal separation performance. The solids are collected in the sludge thickener and transported to the sludge cone with a low friction scraper system. The sludge can be discharged with the sludge pump for thickening or discharge. The Altec+ flotation unit is equipped with a sludge conveyor for discharge of heavy solids.

The Deltec flotation unit is designed to treat wastewater with medium solids loading. The capacity of the Deltec unit ranges from 5 to 200 m3/hr. The Deltec serie is designed to treat the wastewater using the Kemeo Platepack System. The Kemeo Platepack System multiplies the separation surface for effective separation, making it possible to treat a large amount of wastewater on a small footprint. The solids are collected in the sludge thickener and transported to the sludge cone with a low friction scraper system. The sludge can be discharged with the sludge pump for thickening or discharge. The Deltec+ flotation unit is equipped with a sludge conveyor for discharge of heavy solids.

The Gamtec flotation unit is designed to treat waste water with medium solids loading. The capacity of the Gamtec units range from 225 to 600 m3/hr. The Gamtec serie is designed to treat high flows of wastewater using the Kemeo Platepack System. The Kemeo Platepack System multiplies the separation surface for effective separation, making it possible to treat a large amount of wastewater on a small footprint. The solids are collected in the sludge thickener and transported to the sludge cone with a low friction scraper system. The sludge can be discharged with the sludge pump for thickening or discharge.

The Sigtec flotation unit is designed to treat wastewater with medium to high solids loading. The capacity of the Sigtec units ranges from 500 to 1000 m3/hr. The Sigtec series are designed to create the optimal circumstances for easy separation of the solids. The large free surface area and long retention time guarantee an optimal separation performance. The solids are collected in the sludge thickener and transported to the sludge cone with a low friction scraper system. The sludge can be discharged with the sludge pump for thickening or discharge.
