Avantes BV software

To facilitate the use of our AvaSpec series spectrometers, we provide our AvaSoft-Basic, free of charge. It features user-friendly controls, pull down menus and is mouse oriented. Mouse clicks control movements of a data cursor for instantaneous readout of wavelength, pixel and Y-axis magnitude. The multi-window and multi-monitor interface enables side by side comparison of measurements. Use mouse dragging for easy and fast zoom-in/out on both X and Y axes. An unlimited number of AvaSpec series spectrometers can be connected to the computer, either through USB or, by using the AvaGigE, through the network.

For online and offline reflective color measurements, AvaSoft-COL is the ideal companion. This application provides a precise way to perform color measurements using the basic principles and techniques defined by the International Commission on Illumination (CIE). The CIE 1976 L*a*b* color parameters are calculated, along with other parameters, like Hue, Chroma and X, Y, Z. These parameters can be displayed in a CIELAB chart or in a graph versus time. Another possibility is saving the measured L*a*b* values to an online database and using one of the products from the database as a reference color. Color differences (ΔELab, ΔL*, Δa*, or Δb*) are done by comparing the measured L*a*b* values to the stored database values.

Avantes spectrometers measure radiated optical energy, which can be quantified as a radiant flux, in energy per second (Watt) radiated from a source. The radiated optical energy can also be correlated with human vision (photometry), as defined in the CIE, to obtain a spectral luminous efficiency function to characterize the vision of an average human observer. An Avantes irradiance calibrated spectrometer system can measure both radiometric as well as photometric quantities. Radiometric quantities are radiant energy (in Joule), Radiant power or flux (in Watt) or irradiance (Watt per cm2). Related photometric quantities are luminous flux (lumen) or illuminance (lux or lumen per m2).

The AvaSoft-CHEM module enables online concentration determination with a spectroscopy system. Lambert-Beer’s law states there is a linear relationship between absorbance and concentration: A = e * c * l where A is the absorbance (or extinction), e is the extinction coefficient of the compound to be measured, c is the concentration and l is the optical path length.
