Beijing Scitlion Technology Corp., Ltd. products

Calcium Fluoride crystal shows good optical and thermo-mechanical properties, can be used for optical windows, lenses, prisms within a wide range from 130nm to 9μm. It has optical properties of isotropy, low absorption and low refractive index, which made CaF2 gain the unique advantages in the application of high power lasers.

Lithium Fluoride crystal is used as window, lens for the 105nm to 6μm. And also can be used as the optical element in X-ray diffraction devices.

Magnesium Fluoride crystal is used as a lens, prism and window for wavelength from 110nm to 7.5μm. It is a most suitable material as window for ArF Excimer Laser, for the reason of its good transmission at 193nm. It is also effective as an, optical polarizing element in the ultraviolet region. Any more MgF2 crystal has fine grain, which is appropriate as a vacuum evaporation coating materials.

Thallium doped Cesium Iodide (CsI:Tl) as a good performance scintillation crystal, has a broad emission spectrum from 350nm to 700nm, which can match well with SPD. It is suitable used in the application of detecting heavy charged particles under strong γ-rays background.

Thallium doped Sodium Iodide (NaI:Tl) as a good performance scintillation crystal, with very high luminescence efficiency, can be used in the application of Environmental Monitoring, Oil well logging, High-energy Physics and etc.

Operating temperature：-40℃-+100℃. Clear aperture：Φ2mm-Φ50mm. Central wavelength：300nm-1600nm. Transmittanc：≥99.5%.

Dimensional tolerance:±0.1. Focal length tolerance:±1%. Central Thickness tolerance:±0.1. Surface Flatness:λ/4. Surface Quality:II~III.

Material:H-K9. Dimensional tolerance:±0.1. Focal length tolerance:±1%. Central Thickness tolerance:±0.1. Surface Flatness:λ/4. Surface Quality:II~III.
