CAE Software und Systems GmbH products

SoundCam is the first camera that images sound and is affordable for everyone. The system is intuitive and as easy to use as a smartphone. SoundCam locates sound sources in real time and immediately displays the results on the screen.

The Bionic XS-56 microphone array has a diameter of 27 cm and consists of 56 microphones. The optimized microphone distribution guarantees a perfect sound source localization and a high dynamic range. The seven detachable microphone arms (setup about 1 minute) make the system very mobile with a small package size. The data acquisition hardware is integrated in the acoustic camera so there is no need to use external measuring equipement. Using the handle on the acoustic camera makes the system perfect for mobile use. Typical applications are environmental measurement, leakage detection and squeak, buzz and rattle localization.

The Bionic S-112 microphone array has a diameter of 60 cm and consists of 112 microphones. It is engineered for use from 400 Hz. The optimized microphone distribution guarantees a perfect sound source localization and a high dynamic range. The seven detachable microphone arms (setup about 1 minute) make the system very mobile with a small package size. The data acquisition hardware is integrated in the acoustic camera so there is no need to use external measuring equipement. Using the handle on the acoustic camera makes the system perfect for mobile use. Typical applications are environmental measurement, leakage detection and squeak, buzz and rattle localization.

The Bionic M-112 microphone array has a diameter of 100 cm and consists of 112 microphones. It is engineered for use from 40 Hz with the holography-method. The optimized microphone distribution guarantees a perfect sound source localization and a high dynamic range. The seven detachable microphone arms (setup about 1 minute) make the system very mobile with a small package size. Typical applications are wind power plants, gear, industrial facilities and environmental measurement.

The Bionic L-112 microphone array has a diameter of 170 cm and consists of 112 microphones. It is engineered for use from 150 Hz in Farfield. The optimized microphone distribution guarantees a perfect sound source localization and a high dynamic range. The seven detachable microphone arms (setup about 1 minute) make the system very mobile with a small package size. The data acquisition hardware is integrated in the acoustic camera so there is no need to use external measuring equipement. Using the handle on the acoustic camera makes the system perfect for mobile use. Typical applications are wind power plants, gear, industrial facilities and environmental measurement.

The acoustic camera with the special wind turbine microphone array suits perfect with its big diameter of 500 cm for very low frequency sound sources. The 40 microphones are making sound visible and are localizing noise exactly from 50 Hz. The optimized microphone distribution guarantees a perfect sound source localization and a high dynamic range. Although the system has a diameter of 500 cm dismounted it can be convoyed in a car. Setup time is about 30 min. Typical applications are wind power plants, industrial facilities and environmental measurement.

The key components of the system of our partner SM Instruments are online analysis and mobility. The handheld array was honored with the reddot desing award in 2013. The system is often used for measurement from 2000 Hz.

The mobile handheld intensity array is for the localization of low frequencies for stationary and transient noise from 40 Hz. Due to the small size and online analysis, it is a perfect trouble shooter. The detection is done by scanning the surface. The result is a photo or video (acoustic-photo/acoustic-video). Intensity measurements have a very high dynamic range because no algorithms or beampattern are limiting the range.
