Caron S.r.l products

The highest efficiency for any kind of work. Thanks to its remarkable features and to the new CHS System (LINK), this series is the new reference point of the category. The new hydro-pneumatic independent double wishbone suspensions, with automatic level adjustment and suspension lock combine the best off-roads features with an excellent driving on road and allow the transport of any load on every kind of ground. Series CTS has a total approved mass of 10000 kg with a loading capacity of 7000 kg, and the possibilty of towing weights up to 14.000 kg.  4 cylinders Common - Rail engines, with powers from 75 up to 110 hp.

An innovative vehicle designed for the most demanding operators. Series CTA matches the dynamic qualities of Series CTS with the efficiency of Series CT. It is equipped with the new hydro-pneumatic independent double wishbone suspensions system - CHS System (LINK) -  on the front axle ensuring high driving comfort even during long trips. Total approved mass of 10000 kg with a loading capacity of 7000 kg, combined with the possibilty of towing weights up to 14000 kg.  Equipped with the latest generation 4 cylinders Common Rail engines with powers from 75 up to 110 hp.

Series 500 and 600 stay at the top of the Caron range with one seat. These sturdy and professional tractors are designed for those operators requiring the greatest efficiency and reliability, and above all, safety. Total approved weight of 5000 kg (3500 kg for the series 500) and the highest loading capacity of the category: up to 3300 kg. Towing weights up  to 5600 kg. Water-cooled engines with 3 or 4 cylinders, powers from 40 to 63 hp. Series 500 / 600 are available in the articulated or steering wheels versions, with approved closed cab, or open cab or protection arch.

Total approved mass of 3500 kg with loading capacity up to 2000 kg. Designed for those operators demanding the right relationship between dimensions and loading capacity to work in very narrow places without giving up 2 tons of loading capacity. Series 200 and 300 series stay in the middle of the Evo 4 Caron range. they are equipped with 2 or 3 cylinder engines from 25 to 40 hp, with 18-speed gearbox (200 series) or 24-speed synchronized gearbox (300 series). Available in articulated (AR) or front steering wheels (ST) version, with approved closed cab, or open cab or protection arch.

Total approved weight of 3500 kg with loading capacities up to 2200 kg. Series 100 is the smallest model of Caron range. Thanks to the lightweight and small size, this model is extremely agile and handy, ideal for private users. The permanent 4-wheel drive and the double hydraulic circuit braking system on all 4 wheels guarantee safety and stability on every ground. The Lombardini engines - a 25 hp air-cooled 2-cylinder engine or a 40 hp water-cooled 3-cylinders engine, respectively matched with a 9-speed  or a 18-speed mechanical gearbox, offer an excellent fuel consumption/performance ratio. Available in articulated (AR) or front steering wheels (ST) version, with approved closed cab, or open cab or protection arch.

Compact size, high performance. Series CTK has been developed for those operators needing a high-performance vehicle, but with compact size. It has the same mechanical components of the “older sister” CT, but the dimensions are reduced (170 wide) in order to favour the manoeuvrability in narrow spaces. Available with two different Common Rail Turbo engines of 75 hp, has a total approved weight of 7,500 kg, with a loading capacity of 5,000 kg and a towing capacity up to 10,000 kg. Available in different versions and fittings, wheelbases from 2600 to 3000 mm and loading plaform up to 3400 mm long.

The highest loading capacity of the category. Thanks to an excellent weights distribution and the lowest centre of gravity, this transporter is suitable for the most extreme works. The total approved weight of 10000 kg allows the transport of up to 7500 kg loads, combined with towing weights up to 14000 kg.  Equipped with the latest generation 4 cylinders Common Rail engines with powers from 75 up to 110 hp. Available in different versions and fittings, wheelbases from 2600 to 3000 mm.

The right transporter for all kinds of works. For those operators needing a handy and practical vehicle on every grounds without giving up comfort and safety. In spite of the wider inner dimensions of the cab, the Series C is a compact vehicle, with a strong but lightweight structure, easy to handle in any circumstances, on bristly grounds in the forestry and agriculture or through the narrow alleys in historical centres, in the building and municipal field. Engines from 40 to 63 hp, total approved mass of 5000 kg and loading capacity of 3200 kg (towing capacity up to 6000 kg).
