Döbelt Data Communication products

DxINT makes it possible to announce events by SMS, FAX, email, Pager or in the Internet. With DxINT it`s possible to announce events by SMS, FAX, e-mail, pager or on the Internet. In addition you are able to activate a switching output by sending a SMS or email. The DxINT Plug & Play module consists of:

The DxLIFE is a battery supplied data-logger with GSM-transmission. DxLIFE offers different accesses for contacts, (counting -) impulses and measurement signals, for example 0 ..1V/10VS; 0/4 ..20mAs. The power supply of the sensors works via DxLIFE, an additional power supply is not necessary. In order to optimize the energy needs, the internal clock (DCF77) allows the configuration of pre-determined scan dates and/or measure intervals. DxLIFE loggs the data the connected givers and sensors, stores and assesses them and solves alarm-  news over GSM per SMS/FAX / EMAIL/VOICE, at a control station or at DxNET, the internet control station. The collected data are transferred in the end of a measuring period with a GSM/GPRS-connection at a control station and are stored there in a data base.

DxEVENT is an event reporter with battery-supply and GSM/GPRS-modem. the appliance is switched on over an external contact when opening and/or closing. Afterwards, DxEVENT sends the deposited messages to the pre-determined telephone numbers. SMS can be transmitted, also with rear telephone call, email -, FAX - or VOICE - news, just as data send at the internet control station DxNET. After sending the messages, the appliance switches off itself again automatically.

With the FAMO event reporters it`s possible to send FAX texts, beep tones pager messages or sms to radio receicers, phones, FAX devices or data telegrams to a telecontrol station. The Device can be used with or without a fixed network connection, e.g. solely via GSM adapter. By causing a notification, provoked by a change of state at an input of the device, a predefined FAX text, a paging message or a data telegram will be automatically transmitted to one or several receiving stations. The pager calls can be transmitted as text, numerics or tone. 23 news-contacts, to which different FAX texts/beep tones/pager calls/data telegrams are assigned in each case, are available for different events. For each notification eight phone numbers can be defined for the destination of the information transmission, so that e.g. a fax notification and a pager call can be transferred to several receivers at the same time. The operating state and the state of every input are shown in the LCD display.

DxREX is used for the planning and control of task-force-services. Received messages of a telephone-installation, via Email or via SMS or generated by the manual release of a predetermined event can be transmitted to preselected groups. The received messages is distributed to the configured group, a patching of the message through the DxREX is also possible.

The DxCALL system can be put in for applications like for example the person-notification, group alerting or - control. It enables you to report events as SMS, FAX, email and pager call. Additional to single calls can be caused also groups - and collective-notification.

TelREC ist ein Gerät zur Aufzeichnung von Telefongesprächen, z.B. in Notrufzentralen zum Nachweis von Anrufen. Das Gerät hat eine Aufnahmekapazität von bis zu 1950 Stunden. Es ist netzwerkfähig und kann vor unerlaubtem Zugriff geschützt werden (Crypto-Card-Schutz).
