Drumline Ltd products

The 459600802 probe is a low pressure probe from Delta Mobrey (originally Solatron) that is used in the LP Rectangular Section water column. The maximum rating is 50 bar and 260 degrees C. The 459600802 probe is constructed using PTFE insulators, which can be unreliable. Drumline offers a direct replacement for the 459600802 probe. The Drumline DL459600802 is a brazed zirconia probe with an ultra tough bearing grade PTFE coating bonded to the zirconia, this provides a much more reliable probe with higher pressure ratings. Drumline use spiral wound stainless steel and graphite gaskets.

The Hydrastep brand has again been sold. It is now owned by Delta Mobrey. The 459600602 probe is a low pressure probe from Delta Mobrey (originally Solatron) that is used in the LP Rectangular Section water column. The maximum rating is 120 bar and 340 degrees C. Drumline offers a direct replacement for the 459600602 probe. The Drumline DL459600602 is a brazed zirconia probe with very similar construction to the original probe. Drumline use spiral wound stainless steel and graphite gasket

Levelstate Systems Type 811 probe is a low pressure screw fit probe used in the Levelstate Type 501 water column. The Levelstatep DL811 is an ultra high quality 100% completely interchangeable, direct replacement probe. The DL811 is an UPGRADE DIRECT REPLACEMENT for this probe, it uses are PTFE coated brazed zirconia insulator. Drumline manufacture alternate probes that exceed the quality of the OEM part made by Levelstate. This probe is not manufactured by Levelstate Systems.

Levelstate Systems Type 801 probe (Levelstate 801) can be completely replaced by the ultra high quality Drumline Levelstep DL801 Probe. The Drumline Ltd Levelstep DL801 probe is designed and manufactured in the UK as a 100% interchangeable and compatible alternative to the OEM probe. The Levelstate Type 801 is used in the Levelstate Type 501 water column and is rated to 150 bar and 341 degrees C.

The Clark Reliance RZG020RK probe is a gasket seal zirconia insulator based probe used in their EL1800 water column (this is NOT a brazed probe). The stated maximum rating is 1800 psi (124 bar) @ 438 degrees C (821 F). Drumline recommend the use of it`s DLRZ020BRZRK as an upgrade for the Clark Reliance Probe. The DLRZ020BRZRK is a brazed Zirconia probe that uses a spiral wound stainless steel and graphite gasket, instead of the cheaper gaskets used by Clark Reliance.

The Clark Reliance RZG020BRZRK probe is a brazed zirconia insulator based probe used in their EL1800 water column. The stated maximum rating is 1800 psi (124 bar) @ 438 degrees C (821 F). Drumline recommends the use of its DLRZ020BRZRK as an upgrade for the Clark Reliance Probe. The DLRZ020BRZRK is a brazed Zirconia probe that uses a spiral wound stainless steel and graphite gasket, instead of the cheaper gaskets used by Clark Reliance.

The Aquarian 9300-0002 is a high-pressure probe manufactured by Fossil Power Systems. This probe is common in a number of systems that were part of a partnership gone wrong or copied by other companies. Fossil Aquarian, Tyco, Yarway, and Penberthy all share this common design. The pricing on the OEM parts is extremely high for no real reason. The DL964 is a direct replacement for all these probes and is available at a much lower price, but with the same quality and warranty.

The Yarway 964584-01 is a high-pressure probe manufactured by Yarway. This probe is common in a number of systems that were part of a partnership gone wrong or copied by other companies. Fossil Aquarian, Tyco, Yarway, and Penberthy all share this common design. The pricing on the OEM parts is extremely high for no real reason. The DL964 is a direct replacement for all these probes and is available at a much lower price, but with the same quality and warranty. Even though the rating is 370 degrees C and 210 bar. These probes are routinely used for superheated steam applications (560 deg C and 300 bar).

The Yarway 7000044436 is a high-pressure probe manufactured by Yarway. This probe is common in a number of systems that were part of a partnership gone wrong or copied by other companies. Fossil Aquarian, Tyco, Yarway, and Penberthy all share this common design. The pricing on the OEM parts is extremely high for no real reason. The DL964 is a direct replacement for all these probes and is available at a much lower price, but with the same quality and warranty. Even though the rating is 370 degrees C and 210 bar. These probes are routinely used for superheated steam applications (560 deg C and 300 bar).
